Picture of R1/8 Pneumatic Regulator - 0.1bar to 4bar, 10bar max. input, SMC, IR1010-01BG

R1/8 Pneumatic Regulator - 0.1bar to 4bar, 10bar max. input, SMC, IR1010-01BG

The SMC series IR Precision Regulators are designed to be compact and light weight. The maximum set pressure has been expanded from the conventional 0.7MPa to 0.8MPa. Relief flow has been increased by nearly 5 times (compared to SMC IR201, IR401). The optional bracket and pressure gauge can be mounted on either the front or back of the unit.

Precision regulator
Regulating pressure range (MPa): 0.005 to 0.8 depending on model
Compact and lightweight
Bracket & pressure gauge can be mounted on either the front or back
2 air operated models
Manufacturer: SMC
SKU: IR1010-01BG
$209.31
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
FeatureValue
Port ConnectionR1/8
Maximum Outlet Pressure4bar
Minimum Outlet Pressure0.1bar
Maximum Input Pressure10bar
Manufacturer SeriesIR1010
Typical Flow Rate4.4L/min
