Pneumatic Regulators

The SMC regulator is internal pilot relieving style regulator. It has optional bracket and pressure gauge. The regulator verify the pressure that is indicated on the primary and the secondary pressure gauges. Port sizes ranging from 1/4 to 2

The SMC regulator is internal pilot relieving style regulator. It has optional bracket and pressure gauge. The regulator verify the pressure that is indicated on the primary and the secondary pressure gauges. Port sizes ranging from 1/4 to 2

SMC Air Regulator AR20-B - AR40-B SMC’s new AR-B series pneumatic regulators with a pressure range setting of 0.05 to 0.7 MPa or 0.02 to 0.2 MPa. The modular design of these pneumatic regulators allows connection to other SMC air preparation equipment and the AR-B series can be mounted using a bracket or panel mounted. Note An integral Pressure Gauge is shown on the picture for reference only. It is not supplied as a part of the set and has to be bought separately.

The SMC regulator is modular type regulator is available with built-in backflow mechanism. Diaphragm of product is made of ozone resistant rubber material. Optional embedded pressure gauge Rc, NPT or G(PF) threads

The SMC AR-D series of modular pressure regulators are designed for use with AC40-D series of FRLs. This regulator comes without a backflow function, and it has G type pipe threads. The port size of this regulator is 3/4 in and it has a square embedded type pressure gauge (with limit indicator). Set pressure for this regulator is 0.02 to 0.2 MPa Models with the backflow function include a mechanism which allows for the air pressure in the outlet side to be released to the inlet side

The SMC AR-D series of modular pressure regulators are designed for use with AC40-D series of FRLs. This regulator comes without a backflow function, and it has G type pipe threads. The port size of this regulator is 3/4 in and it has a round type pressure gauge (with limit indicator). Set pressure for this regulator is 0.05 to 0.85 MPa Models with the backflow function include a mechanism which allows for the air pressure in the outlet side to be released to the inlet side

The SMC AR-D series of modular pressure regulators are designed for use with AC40-D series of FRLs. This regulator comes with a backflow function, and it has G type pipe threads. The port size of this regulator is 3/4 in and it has a square embedded type pressure gauge (with limit indicator). Set pressure for this regulator is 0.05 to 0.85 MPa Models with the backflow function include a mechanism which allows for the air pressure in the outlet side to be released to the inlet side

The SMC AR-D series of modular pressure regulators are designed for use with AC40-D series of FRLs. This regulator comes with a backflow function, and it has G type pipe threads. The port size of this regulator is 3/4 in and it has a round type pressure gauge (with limit indicator). Set pressure for this regulator is 0.05 to 0.85 MPa Models with the backflow function include a mechanism which allows for the air pressure in the outlet side to be released to the inlet side

The SMC AR-D series of modular pressure regulators are designed for use with AC50-D series of FRLs. This regulator comes without a backflow function, and it has G type pipe threads. The port size of this regulator is 3/4 in and it has a round type pressure gauge (with limit indicator). Set pressure for this regulator is 0.05 to 0.85 MPa Models with the backflow function include a mechanism which allows for the air pressure in the outlet side to be released to the inlet side

The SMC AR-D series of modular pressure regulators are designed for use with AC50-D series of FRLs. This regulator comes with a backflow function, and it has G type pipe threads. The port size of this regulator is 3/4 in and it has a square embedded type pressure gauge (with limit indicator). Set pressure for this regulator is 0.05 to 0.85 MPa Models with the backflow function include a mechanism which allows for the air pressure in the outlet side to be released to the inlet side

The SMC AR-D series of modular pressure regulators are designed for use with AC50-D series of FRLs. This regulator comes with a backflow function, and it has G type pipe threads. The port size of this regulator is 3/4 in and it has a round type pressure gauge (with limit indicator). Set pressure for this regulator is 0.05 to 0.85 MPa Models with the backflow function include a mechanism which allows for the air pressure in the outlet side to be released to the inlet side

The SMC air regulator has a square embedded type pressure gauge with the air flow direction from left to right. The regulator does not have back flow function and has a relieving type of exhaust mechanism. Maximum flow rate up to 5000 litre per minute Weight is 0.51 kg Has a downward knob Easy to handle
