Solenoid Valve , 3 port(s) , NO/NC, 24 V dc, 1/4in, SMC, VDW350-5G-4-02F-Q

Three Port Solenoid Valves

The VXA series of valves can be used with a wide variety of fluids. The VXA31/32 manifold is individual ported; valves for both are easily replaced without changing existing piping.

Compatible with a wide range of fluids
Manufacturer: SMC
SKU: VDW350-5G-4-02F-Q
$79.71
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
FeatureValue
Supply Voltage24 V dc
Number of Ports3
Connection Size1/4in
Connection1/4 in G Female
OperationDirect
Default Valve PositionNO/NC
Suitable ApplicationsAir, Low Vacuum, Water
Type3/2
Orifice Diameter1.8 mm, 4mm
SeriesVDW300
Body MaterialBrass
Maximum Working Pressure1 MPa
Operating Temperature Range-10 → +50 °C
Thread Standard or Connection TypeG
Minimum Operating Temperature-10°C
Connection GenderFemale
Maximum Operating Temperature+50°C
