Picture of Rc 3/8 Pneumatic Regulator - 0.01MPa to 0.8MPa, 3/8in, 1MPa max. input, SMC, IR3020-03

Rc 3/8 Pneumatic Regulator - 0.01MPa to 0.8MPa, 3/8in, 1MPa max. input, SMC, IR3020-03

Precision regulator
Regulating pressure range (MPa): 0.005 to 0.8 depending on model
Compact and lightweight
Bracket & pressure gauge can be mounted on either the front or back
2 air operated models
Manufacturer: SMC
SKU: IR3020-03
$409.82
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
FeatureValue
Port ConnectionRc 3/8
Maximum Outlet Pressure0.8MPa
Minimum Outlet Pressure0.01MPa
Maximum Input Pressure1MPa
Manufacturer SeriesIR3000
Pressure Gauge Port SizeRc 1/8
Port Connection Thread Size3/8in
Pressure Gauge Port Thread Size1/8in
Maximum Flow Rate11.5L/min
Port Connection Thread StandardRc
Minimum Operating Temperature-5°C
Maximum Operating Temperature+60°C
Overall Width50mm
Overall Dimensions50 x 50 x 124mm
Overall Height124mm
Overall Length50mm
