Picture of Rc 1/8 Pneumatic Regulator - 0.01MPa to 0.8MPa, 1/8in, 1MPa max. input, SMC, IR1020-01

Rc 1/8 Pneumatic Regulator - 0.01MPa to 0.8MPa, 1/8in, 1MPa max. input, SMC, IR1020-01

Precision regulator
Regulating pressure range (MPa): 0.005 to 0.8 depending on model
Compact and lightweight
Bracket & pressure gauge can be mounted on either the front or back
2 air operated models
Manufacturer: SMC
SKU: IR1020-01
$196.33
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
FeatureValue
Port ConnectionRc 1/8
Maximum Outlet Pressure0.8MPa
Minimum Outlet Pressure0.01MPa
Maximum Input Pressure1MPa
Manufacturer SeriesIR1000
Pressure Gauge Port SizeRc 1/8
Port Connection Thread Size1/8in
Pressure Gauge Port Thread Size1/8in
Maximum Flow Rate4.4L/min
Port Connection Thread StandardRc
Minimum Operating Temperature-5°C
Maximum Operating Temperature+60°C
Overall Height92mm
Overall Length35mm
Overall Width35mm
Overall Dimensions35 x 35 x 92mm
