Picture of Pneumatic Solenoid Valve - Solenoid G 1/8 VZ500 Series 24V dc, SMC, VZ512-5MNZ-01F-Q

Pneumatic Solenoid Valve - Solenoid G 1/8 VZ500 Series 24V dc, SMC, VZ512-5MNZ-01F-Q

VZ5000 Solenoid Valves

5 Port, body ported solenoid valves from SMC’s V5000 series for inline mounting. Suitable for use with cylinders up to a bore of 50mm, the VZ5000 is compact in size with a width of just 15mm and energy efficient with a low power consumption of just 1.8W DC. Fitted with non-locking push type manual override.

SMC SY & VZ Series

These valves can be used singly or with a manifold system. Low power consumption enables direct operation by PLC. They have a Non locking manual override.
Manufacturer: SMC
SKU: VZ512-5MNZ-01F-Q
$218.28
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
FeatureValue
Connection Port ThreadG 1/8
Actuation TypeSolenoid
Manufacturer SeriesVZ500
Mounting StyleBase Mount
Solenoid Voltage24V dc
Number of Ports5
Body MaterialDie Cast Aluminium
Solenoid Power Consumption1.8W
Minimum Operating Pressure0.15MPa
Thread Size1/8in
ConfigurationNormally Closed
Number of Positions2
Maximum Operating Pressure0.7 MPa
Minimum Operating Temperature-10°C
Maximum Operating Temperature+50°C
Special FeaturesLow Power Consumption, Applicable for Vacuum Use
Thread StandardG
