Pneumatic Manual Control Valves

Roller Lever/Spring Valves 3//2 normally closed valves with a CV 0.055 flow. Each valve incorporates built in hose nipple connection suitable for Ø4mm OD, 2.5mm ID tube. Miniature stucture requires little mounting space Built-in hose nipple connection Dedicated valves must be used for nylon or polyurethane tubing These valves are interchangeable with V3 electrical switches

One Way Trip Valve 3//2 normally closed valves with a CV 0.055 flow. Each valve incorporates built in hose nipple connection suitable for Ø4mm OD, 2.5mm ID tube Dedicated valves must be used for nylon or polyurethane tubing These valves are interchangeable with V3 electrical switches

Roller Lever/Spring Valves

Roller Lever/Spring Valves

The SMC VM800 is 3 port heavy duty mechanical valve. The normally closed and normally open model is available. It has many actuator positions and orientation options. Sturdy Construction Piping possible to any port

The SMC VFM series is very compact and high capacity 5 port mechanical valve. High frequency Long lifespan Piping possible to any EXH port

The SMC VM100 series is a mechanical, poppet valve. Their compact size requires little mounting space. The VM series offers a wide variety of actuator styles and flow capacity up to 1.0 Cv. Light weight Operating pressure from -100kPa to 1.0MPa Ambient and fluid temperature from -5° to 60°C

The SMC VM100 series is a mechanical, poppet valve. Their compact size requires little mounting space. The VM series offers a wide variety of actuator styles and flow capacity up to 1.0 Cv. Light weight Operating pressure from -100kPa to 1.0MPa Ambient and fluid temperature from -5° to 60°C

VM100 Series Roller Lever & Plunger Valves A selection of lever valves from SMC’s durable VM series suitable for harsh conditions and now redesigned to be lighter and more compact. Available with various actuator types that are simple to change or replace and available with either a 1/8” ort size (VM100) or1/4"” (VM200).Suitable for a wide range of applications, including vacuum, the VM 100/200 is ideal for pneumatic control panels and confirming the position of a workpiece using a pneumatic sign

The SMC VM800 series is a mechanical, poppet valve. Their compact size requires little mounting space. The VM series offers a wide variety of actuator styles and flow capacity up to 1.0 Cv. Operating pressure -100kPa to 1.0MPa Effective area (Cv) 6mm 2 (0.33) Ambient and fluid temperature -5° to 60°C (no freezing)

The SMC Pneumatics VM131-F01-01A is 2/3-Port Mechanical valve. Built-in One-touch fitting reduced installation space and less piping work. Control Mechanism Roller Lever Connection Port Thread G 1/8 Thread Size 42948 Thread Standard G

VM100 Series Roller Lever & Plunger Valves A selection of lever valves from SMC’s durable VM series suitable for harsh conditions and now redesigned to be lighter and more compact. Available with various actuator types that are simple to change or replace and available with either a 1/8” ort size (VM100) or1/4"” (VM200).Suitable for a wide range of applications, including vacuum, the VM 100/200 is ideal for pneumatic control panels and confirming the position of a workpiece using a pneumatic sign
