Picture of Pneumatic Guided Cylinder - 32mm Bore, 50mm Stroke, MGQ Series, Double Acting, SMC, EMGQM32-50

Pneumatic Guided Cylinder - 32mm Bore, 50mm Stroke, MGQ Series, Double Acting, SMC, EMGQM32-50

MGQ series compact guide cylinders

Very high resistance to radial loads.
Use with lubricated or unlubricated air.
Fixing on both sides.
Sensors fitted in the cylinder body.

MGQ-M Compact Guided 12-50mm Diameter

Compact, double-acting guided cylinders utilising slide bearings. These cylinders maintain a very high non-rotational accuracy and have a high tolerance to side loading. All cylinders have magnetic sensing capabilities and direct mount facilities.
Manufacturer: SMC
SKU: EMGQM32-50
$1,082.36
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
FeatureValue
Stroke50mm
Bore32mm
Manufacturer SeriesMGQ
ActionDouble
Maximum Operating Pressure1 MPa
Cushioning TypeRubber
Dimensions121.5 x 51 x 114mm
Weight1.9kg
Maximum Operating Temperature+60°C
Length121.5mm
Width51mm
Height114mm
Minimum Operating Temperature-10°C
