Picture of Pneumatic Guided Cylinder - 25mm Bore, 50mm Stroke, MGQ Series, Double Acting, SMC, EMGQM25-50

Pneumatic Guided Cylinder - 25mm Bore, 50mm Stroke, MGQ Series, Double Acting, SMC, EMGQM25-50

MGQ series compact guide cylinders

Very high resistance to radial loads.
Use with lubricated or unlubricated air.
Fixing on both sides.
Sensors fitted in the cylinder body.

MGQ-M Compact Guided 12-50mm Diameter

Compact, double-acting guided cylinders utilising slide bearings. These cylinders maintain a very high non-rotational accuracy and have a high tolerance to side loading. All cylinders have magnetic sensing capabilities and direct mount facilities.
Manufacturer: SMC
SKU: EMGQM25-50
$635.82
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
FeatureValue
Stroke50mm
Bore25mm
Manufacturer SeriesMGQ
ActionDouble
Maximum Operating Pressure1 MPa
Cushioning TypeRubber
Dimensions97.5 x 42 x 88mm
Weight1.1kg
Maximum Operating Temperature+60°C
Length97.5mm
Height88mm
Width42mm
Minimum Operating Temperature-10°C
