Picture of Pneumatic Guided Cylinder - 16mm Bore, 20mm Stroke, MGQ Series, Double Acting, SMC, MGQM16-20

Pneumatic Guided Cylinder - 16mm Bore, 20mm Stroke, MGQ Series, Double Acting, SMC, MGQM16-20

MGQ series compact guide cylinders

Very high resistance to radial loads.
Use with lubricated or unlubricated air.
Fixing on both sides.
Sensors fitted in the cylinder body.

MGQ-M Compact Guided 12-50mm Diameter

Compact, double-acting guided cylinders utilising slide bearings. These cylinders maintain a very high non-rotational accuracy and have a high tolerance to side loading. All cylinders have magnetic sensing capabilities and direct mount facilities.
Manufacturer: SMC
SKU: MGQM16-20
$461.24
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
FeatureValue
Stroke20mm
Bore16mm
Manufacturer SeriesMGQ
ActionDouble
Maximum Operating Pressure1 MPa
Cushioning TypeRubber
Dimensions63 x 33 x 64mm
Weight390g
Maximum Operating Temperature+60°C
Length63mm
Width33mm
Minimum Operating Temperature-10°C
Height64mm
