Picture of SMC CDQ2A12-10DMZ-M9NV Cylinder, CQ2-Z Compact Cylinder

SMC CDQ2A12-10DMZ-M9NV Cylinder, CQ2-Z Compact Cylinder

SMC has redesigned the CQ2 compact cylinder with a new body, making it possible to mount auto switches on any of the 4 surfaces, depending on the installation conditions. Auto switch mounting grooves have replaced the CQ2s mounting rails, preventing projection of auto switches and improving ease and safety of work.
Manufacturer: SMC
SKU: CDQ2A12-10DMZ-M9NV
Please send us an email to enquire about this item.
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

SMC has redesigned the CQ2 compact cylinder with a new body, making it possible to mount auto switches on any of the 4 surfaces, depending on the installation conditions. Auto switch mounting grooves have replaced the CQ2s mounting rails, preventing projection of auto switches and improving ease and safety of work.

  • Double acting, single rod, compact cylinder
  • Bore sizes *: 12, 16, 20, 25, 32, 40, 50, 63, 80, 100
  • Standard stroke range *: 5 to 100
  • Port threads: M *; Rc, NPT or G *
  • Auto switch capable

Technical Specifications

SMC Part DescriptionCylinder
SMC Products LineActuator
SMC Class Description12MM CQ2-Z DBL-Act Auto-SW
Weight0.18 kg
SMC Family CodeFE
